The fan is consist of AC induction motor with inner or external rotor and plastic or metal impeller, has the following feature: big air flow, low noise&vibration, reliable connection, easy mounting and long life-time etc. The FZL series fans are mainly used in computer systems, ground-based auto-controlling equipment, electronic instruments, office automatic equipment, medical apparatus and welding machines.



型 号         Type	电压    V	频率  Hz	相数   Phase	输入功率 W	电流   A	转速r/min	风量M3/min	噪音  dB	重量  Kg	电容        μF/V	轴承形式  Bearing style
250FZL2	220	50	1	40	0.2	1300	12	60	2.1	1.0/400	G
250FZL3	380	50	3	40	0.12	1300	12	60	2.1		G
250FZL6	220	50	1	100	0.5	2500	22	70	2.5	3.0/400	G
250FZL7	380	50	3	100	0.3	2500	22	70	2.5		G
