The fan is consist of AC induction motor with inner or external rotor and plastic or metal impeller, has the following feature: big air flow, low noise&vibration, reliable connection, easy mounting and long life-time etc. The FZL series fans are mainly used in computer systems, ground-based auto-controlling equipment, electronic instruments, office automatic equipment, medical apparatus and welding machines.



型 号         Type	电压    V	频率  Hz	相数   Phase	输入功率 W	电流   A	转速r/min	风量M3/min	噪音  dB	重量  Kg	电容        μF/V	轴承形式  Bearing style
186FZL2	220	50	1	50	0.3	2600	11	68	1.8	1.0/400	G
186FZL3	380	50	3	50	0.18	2600	11	68	1.8		G
200FZL2	220	50	1	65	0.3	2600	13	68	1.8	1.0/400	G
200FZL3	380	50	3	65	0.18	2600	13	68	1.8		G
