The fan is consist of AC induction motor with inner or external rotor and plastic or metal impeller, has the following feature: big air flow, low noise&vibration, reliable connection, easy mounting and long life-time etc. The FZL series fans are mainly used in computer systems, ground-based auto-controlling equipment, electronic instruments, office automatic equipment, medical apparatus and welding machines.



型 号         Type	电压    V	频率  Hz	相数   Phase	输入功率 W	电流   A	转速r/min	风量M3/min	噪音  dB	重量  Kg	电容        μF/V	轴承形式  Bearing style
145FZL2	220	50	1	35	0.18	2600	5.5	55	1	1.0/400	G
145FZL3	380	50	3	35	0.1	2600	5.5	55	1		G
