The TDY-C motor is consist of TDY motor and high reliable planetary gear box, which has many features, such as compact construction, constant speed, high torque. There will be no impact current when the motors start, brake, reverse and stall instantly. The motors have certain holding torque, if they are excited by DC power, they will produce high holding torque. In addition, the motor can start, brake, reverse and stall instantly. They also can drive high inertia loading, and are mainly used in industrial automation, electric valve actuator, feed mechanism of lathes, medical apparatus, automatic production line, barrier gate, packaging machinery, textile machinery as super low speed and super low speed and super high torque driving devices.

型号	电压 V	频率 Hz	输入电流 A		输入功率 W	同步转速 r/min	最大转矩 mN.m		额定转矩 mN.m		启动转矩 mN.m		电容 μF/V	电阻 Ω/W
130TDY-C	220	50	0.80		150	60	7500		6000		3800		6.0/500	360/100
	齿轮箱转速		三级变速后转速(r/min)				二级变速后转速(r/min)
			1.2	2	3	4	5	6	8	10	12	15	20	30
	转矩N.M		352	211.2	140.8	150.6	95	79.2	59.4	47.5	39.6	31.7	23.8	15.8
